Monturi & accesorii > Monturi > Ecuatoriala cu GoTo > iOptron > CEM > iOptron Montura CEM70 ECW iPolar
Nr. articol: 76347

Montura CEM70 ECW iPolar

$ 5.900,00 incl. TVA, plus costuri de livrare
prea scump?
termen scurt
gata de livrare in 3-5 saptamani + timp de tranzit

Descriere produs

Mai multe despre această serie CEM...

Din pacate, descrierea acestui produs nu a fost inca tradusa in limba romana, din acest motiv veti gasi in loc o descriere in limba engleza.

The advantages at a glance:

  • A new design, center-balanced equatorial mount (CEM) for maximum payload with natural stability
  • Ideal for both visual observation and astrophotography
  • Payload of 70 lbs (31.8 kg) with the mount weight of 30 lbs (13.6 kg)
  • Easy to use and reliable gear clutches
  • Precision altitude and azimuth adjustment.
  • Precision stepper motor with 0.07 arcsec accuracy for precise GOTO and accurate tracking
  • iPolar electronic polar scope
  • Go2Nova® 8410 controller with advanced GOTONOVA® technology and a built-in heater
  • High precision tracking with low periodic error (PE <0.3 arcsec rms)
  • realtime periodic error correction (RPEC)
  • 32-channel Global Positioning System (GPS)
  • USB 3.0 powered connection
  • Integrated ST-4 autoguiding port
  • Advanced cable management system with more choices
  • Spring loaded 8" Vixen/Losmandy dual saddle
  • Built-in Wi-Fi connectivity

Following up on the success of the iOptron CEM60 center balance equatorial mount, iOptron is introducing two new medium payload center balance mounts. The CEM70 series mounts are new standard bearers for equatorial mounts in the 70lb payload segment. The mounts are packed with advanced features, while streamlining the components resulting in a more portable imaging setup.

Retaining the inherent properties of the center balance design, these relatively compact medium payload mounts deliver what astronomers expect in an efficient, accurate and portable mount. With precise GOTO pointing and accurate tracking, the CEM70EC is a solid performer for observers and imagers alike. Innovative operational features such as the internal iPolar electronic polar scope, easy lock drive gear engagement (levers large enough to use with gloves), an advanced cable management system for the mount, iPolar, guider, and camera assure users that the CEM70 was designed with their needs in mind.

Comentariul expertilor nostrii:

Din pacate, descrierea acestui produs nu a fost inca tradusa in limba romana, din acest motiv veti gasi in loc o descriere in limba engleza.

The CEM70 ECW has a high precision encoder on the RA axis.

The CEM70 ECW2 has precision encoders on both, the Dec and RA axis. Both versions have an iPolar.

(Jan Stroeher)

If there are small discrepancies when the “zero position” is first activated, iOptron has provided advice to resolve this:

"Search zero position is a function to bring the mount to a rough zero, a few degrees off is possible. At the end of Search Zero, it will ask calibration. Use arrow keys to move RA and DEC to adjust the positions to physical zero position. When done, set zero position. This position will be memorized in the controller as Zero Position.

One may further refine zero position by the following steps:

Search zero -> goto a bright star and center it ->sync to target -> goto zero position ->set zero position.

This is a true (accurate) zero position."

(Jan Ströher)

Date tehnice

Capacitate


Denumire
CEM70 ECW
Incarcare maxima (kg)
31.8
Greutate doar cap montura (kg)
13,6
Contragreutate/contragreutati
1 (9,5kg)
Interfete
ST-4 & USB 3.0
Surse de curent
12
Limba meniu
Engleza
Reglaj inaltime axa polara (°)
0-65
Reglaj azimutal fin (°)
+/- 4
Temperatura de operare
-10 bis +40
Viteza motor
1x, 2x, 8x,16x, 64x, 128x, 256x, 512x, max ~3.75º/sec
Suport de montare
Losmandy & Vixen
Diametru rulmenti DEC (mm)
80
Diametru rulmenti RA (mm)
80
Diametru coroana melcata DEC (mm)
151
diametru spirala melc RA (mm)
151
Coroana dintata (DEC)
248
Coroana dintata (RA)
248
Encoder
da
Precizie urmarire
0,07
Diametru coloana melcata (mm)
55
Diametru ax melc DEC (mm)
55
Diametru tija contragreutati (mm)
28
Material coroana
Otel
Tip motor
Motoare pas cu pas (128 micro-steps)
Ghidaj prin cablu
intern

Extras


Sistem GoTo
da
GPS
da
Controler
da

Echipare


Cutii transport
da
Trepied
fara trepied
Luneta polara
da
Adaptor retea
da
Contragreutati
1

General


Greutate totala (kg)
24
Serii
CEM
Tip
Montura
Tip constructiv
ecuatoriala

Aplicaţii


Util pentru fotografiere
da
Util vizual
da

Control GoTo


GPS
da
cu unitate manuala
da
WIFI
da
Interfete
Autoguider, USB
Autoguiding
da
Corectie PEC
da
Aliniere Polara
iPolar
Limba GoTo
Engleza
